EPIC RED的官方 DEMO REEL

west

Demo 影片位置:
http://www.red.com/experience/red_reels

Tech Specs

SENSOR	14 MEGAPIXEL MYSTERIUM-X™
PIXEL ARRAY	5120 (h) x 2700 (v)
S/N RATIO	66db
DYNAMIC RANGE	13.5 stops, up to 18 stops with HDRx™
MAX IMAGE AREA	5120 (h) x 2700 (v)
LENS COVERAGE	27.7mm (h) x 14.6mm (v) x 31.4 mm (d)
DEPTH OF FIELD	Equivalent to S35mm (Motion) / APS-H (Still) lenses Equivalent to 16mm (Motion) lens in 2K RAW
ACQUISITION FORMATS	5K RAW (Full Frame, 2:1, 2.4:1 and Anamorphic 2:1) 4.5K RAW (2.4:1) 4K RAW (16:9, HD, 2:1 and Anamorphic 2:1) 3K RAW (16:9, 2:1 and Anamorphic 2:1) 2K RAW (16:9, 2:1 and Anamorphic 2:1) 1080p RGB (16:9) 720p RGB (16:9)
PROJECT FRAME RATES	23.98, 24, 25, 29.97, 47.96, 48, 50, 59.94 fps, all resolutions
DELIVERY FORMATS*	4K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 2K : DPX, TIFF, OpenEXR (RED RAY via optional encoder) 1080p RGB or 4:2:2, 720p 4:2:2 : Quicktime, JPEG Avid AAF, MXF. 1080p 4.2.0, 720p 4:2:0 : H.264, .MP4
PROGRAM OUTPUT	HD-SDI Clean Feed 2K RGB, 1080p RGB or 4:2:2, 720p 4:2:2 SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
MONITOR OUTPUT	HD-SDI and HDMI with Frame Guides and Look Around 2K RGB, 1080p RGB or 4:2:2, 720p RGB or 4:2:2 SMPTE Timecode, HANC Metadata, 24-bit 48Khz Audio
DIGITAL MEDIA	REDFLASH (CF) Module : (8, 16GB Media) REDFLASH (SSD) Module : (64, 128, 256GB Media)
REDCODE™	12 and 16-bit RAW : Compression choices of 18:1 to 3:1 1-120 fps 5K, 4.5K 1-150 fps 4K 1-200 fps 3K 1-300 fps 2K
AUDIO	2 channel, uncompressed, 24 bit, 48KHz. Optional 4 channel, and AES / EBU digital audio.
MONITORING OPTIONS	RED LCD 5" Touchscreen Display BOMB EVF™ High Definition Viewfinder
REMOTE CONTROL	Wireless, Ethernet, RS232, GPI Trigger
WEIGHT	5lbs. Body only
CONSTRUCTION	Aluminum Alloy
TEMPERATURE RANGES	Operating Range: 0˚C to +40˚C (32˚F to 104˚F) Storage Range: -20˚C to +50˚C (-4˚F to 122˚F)
* FROM REDCINE-X

asa00322

相較於這些，目前的FULL-HD好像玩具一般，
多年後回頭看這些影片，似乎是現在回頭看DV帶子一般，
也期待4K以上的設備能夠盡速的親民化。

htjmartin

本文章最後由 htjmartin 於 2011-7-13 04:13 編輯

畫質真的是好到沒話說
整個介紹片都是慢動作，這個很吸引人，不用再另外租高速攝影機。

EPIC最好的地方應該在它的機身小，片段有一個兩人騎腳踏車還可以單手拿

west

EPIC 台灣已經進來第一部了，這樣的好物不拿來玩玩拍些東西太對不起自己了!!

west

Drip: RED EPIC 300 FPS test shoot
by Philip Bloom

[vimeo=25591100,960]360[/vimeo]

My first time shooting with the EPIC. I had just downloaded the new firmware which upped the FPS from 120 to 300 FPS albeit at a drop in resolution to 2K.

Not knowing the camera at all, with a little shoot coming up I wanted to test it out and get my head around the camera and workflow whilst I was at the Kessler Crane HQ. I had to shoot something to test it out so thought to myself "Why not throw loads of water at my mate Eric Kessler?". So I did and here it is. Nothing original, but I have never done it and have never shot anything over 60 FPS before so a real treat for me, especially as Eric was the victim!

All shot with Zeiss CP.2 35mm.

Music Wigwam by Bob Dylan

More info on my site gopb.co/​REDEPIC300FPS

Thanks to Eric, RED, Sarah, Chris, Theresa, Kessler Crane, Michael Sutton of Boston RULE camera, Wooden Camera.

2266MTV

挖塞    畫質真的超棒滴         看了很震撼說        這個很像 8x10"  單張的大像機

光解析度   就很有質感說

htjmartin

回覆 5# west

呵呵，有點莫名其妙的短片，好像是趁機要惡搞那位仁兄 呵
要嘛也應該找個穿比基尼的美女來試才對

west

RED EPIC 第一次接觸
目前台灣第一部由宏達數位引進，精研首部4K作品即將誕生!!

dyeverywhere

那就請站長測試白色比基尼潑溼

asa00322

那就請站長測試白色比基尼潑溼
dyeverywhere 發表於 2011-7-18 19:07

"站長"親自測試??

525i

還真想猜看看精研首部4K的作品會是什麼? 不知最近有什麼好題材..

west

還真想猜看看精研首部4K的作品會是什麼? 不知最近有什麼好題材..
525i 發表於 2011-7-18 19:53

機密!!
看了會流口水的那種就對了!!

sendoh0605

要命~科技進步太快哩~!要跟上真要敗口袋深度阿~!

facelover

機密!!
看了會流口水的那種就對了!!
west 發表於 2011-7-19 07:17

打敗肉蒲團? 有需要男優嗎?

getrouble

其實... 在去年小弟還在前公司就非常關注 EPIC..
一些相關資訊也可以參考 http://ts-mediastudio.blogspot.com/search/label/5K

如果買來.. 也可當作兩千萬像素的相機.. 性能上比現行的DSLR好多了...
不過價格跟麻煩的程度.. 則高出甚多....
