Display device | 0.65" DLP chip |
Resolution | 1080p (1920 x 1080) |
Brightness | 1,600 ANSI lumens |
Contrast ratio | 40,000:1 (in High Contrast mode) |
Lens | F number | F 2.5 ~ 2.7 |
Zoom | Manual, x1.15 (f = 21.0 ~ 24.2 mm) |
Focus | Manual |
Picture size | 40" (102 cm) to 500" (1,270 cm) |
Projection distance | 40": 1.3 ?1.4 m, 100": 3.1 ?3.6 m, 500": 15.7 m |
Input signals | DTV | 1080p / 1080i / 720p / 576p / 540p / 480p / 480i |
|
NTSC / PAL / SECAM |
Computer RGB | WSXGA+ / SXGA+ / SXGA / WXGA / XGA / SVGA / VGA |
|
Mac 21" / 19" / 16" / 13" |
Input terminals | HDMI | x 2 |
Computer / Component (mini D-sub 15 pin) | x 1 |
Component (3 RCA) | x 1 |
S-Video (mini DIN 4 pin) | x 1 |
Video (RCA) | x 1 |
Control and communication terminals | RS-232 (mini DIN 9pin) | x 1 |
Projection lamp | 250 W |
Lamp life | 3,000 hrs (Eco+Quiet Mode) |
Replacement lamp | AN-K15LP |
Fan noise | 23 dB (Eco+Quiet Mode) |
Horizontal frequency | 15 ?110 kHz |
Vertical frequency | 43 ?85 kHz |
Rated voltage | AC 100 ~ 240V |
Rated frequency | 50 / 60 Hz |
Input current | 3.7 A |
Power consumption (*Standby) | 339 W (8.3 W*) with AC 240V |
|
353 W (7.6 W*) with AC 100V |
Operation temperature | +5o C to +35o C |
Dimensions (main body) [W x H x D] | 400 x 100 x 335 mm |
Weight (approx.) | 5.8 kg |
Supplied accessories | 2 pairs of 3D glasses (AN3DG10S), Remote control, Two AA batteries, Power cord (1.8m), Operation manual |
