市場上越來越多前端影像設備開始支援 HDMI 的 4K 輸出,因此 4K 外部記錄器的需求肯定會越來越多。如 Sony A7S 發表時,就是搭配 Atomos 的 4K 記錄器 Shogun 一同亮相。
就在 Shogun 即將在這個月正式供貨之際,另一家記錄器廠商 Convergent-Design 公司今天以迅雷不及掩耳的速度發表了 Odyssey7Q+,並宣稱同樣於本月中開始出貨。美金售價為 2,295 (比 Shogun 的 1,995 稍貴)。
目前看來擴充性及攝影機的支援度上 Odyssey7Q+ 似乎更有彈性,但體積也相對更大了些。所以在行動性及功能性上的取捨就交由使用者來決定囉。
Odyssey7Q+ 除了能採用 ProRes 422 (HQ) 進行 4K/HD 記錄,跟之前的 Odyssey7Q 一樣能透過選購擴充的方式,支援不同機種的 RAW 檔記錄。記錄媒體採雙 SSD 設計,可以滿足需要長時間工作的使用需求。
以下為 Odyssey7Q+ 相關規格整理
HDMI and SDI I/O - HD/2K/UHD/4K Recording over HDMI or SDI w/ conversion
LUT SUPPORT - ARRI Log-C, CANON C-Log, SONY S-Log, S-Log 2, S-Log 3
ASPECT RATIO GUIDES - Standard and Custom (user adjustable), may be used for framing guides, Horizontal/Vertical Framing Guides Available
FOCUS ASSIST - Video + Edges (Peaking), Edges Only, Enhanced Edges, user choice of color: Red, Green, or Blue
ZEBRAS - Adjustable zebra exposure indicators
FALSE COLOR - False Color with 5 programmable levels
WAVEFORM - Luma only, RGB Parade, Red only, Blue only, Green only, Full Size and Compact Size options
HISTOGRAM Luma only, RGB Parade, Red only, Blue only, Green only, Full Size and Compact Size Options
PIXEL ZOOM - 1:1 and 2:1 Image Magnification with frame drag
OUTPUT DOWNSCALING - Output 1080p HD via HDMI or SDI from 4K/UHD source (allows for additional on-set monitoring)
MULTI-STREAM DISPLAY - Display four simultaneous 1080 or 720 HD streams, HD-SDI and HDMI inputs supported in multiple formats
DIGITAL/ANALOG AUDIO - Multi-channel audio support via SDI, HDMI or 3.5mm analog ports
TIMECODE - Timecode: LTC I/O (BNC) or embedded timecode via HD-SDI & HDMI (limited to specific cameras
IN/OUT MARKERS - In/Out markers set during recording can be used during start/stop/playback and exported to NLE.
UPGRADEABLE - RAW Recording Options available for purchase or rental through our website. (Sony RAW, Canon RAW, ARRIRAW, POV Raw)
DUAL SSD SUPPORT - Dual drive architecture allows for long record time, high frame rate and high data rate recording.
RUGGED DESIGN - Magnesium alloy case for extreme durability in harsh conditions
|
|
