Sony 傳說中的手持型35mm攝影機 PMW-F3 即將登場

alex

Our new vision for 35mm style acquisition

As the demand for digital shooting with a 35mm size sensor increases, we are extending the range and capabilities of Sony cameras and camcorders to ensure everyone can stun audiences with 35mm cinematic impact.

From the highest-end feature films to tighter budget productions, we want to ensure that every content creator has precise control over depth of field and access to the huge range of cinematic lenses available.

With the world’s most renown professionals already using the Sony flagship F35 camera, our 35mm technology combines superior image quality with hardware reliability and smooth workflow management.

Now – building on our unrivalled heritage in Digital Cinematography, from digital HD acquisition to our legendary CineAlta range – we are applying our unique expertise to creating 35mm cameras for professionals at every level. With Sony, everyone can experience the world of 35mm shooting.








More choice for high-end performance
The cinematic artistry afforded by 35mm is a prerequisite for big budget filmmakers, and our hugely successful F35 camera has set new standards for digital acquisition. Now we have packed the legendary performance of the F35 into our new SRW-9000PL camcorder. Using the same Super 35mm CCD sensor and PL mount as the F35, the SRW-9000PL captures breathtaking images and ensures compatibility with the wide choice of PL mount lenses and film-style accessories. Recording in HDCAM SR also guarantees excellence in post – a benefit that has ensured its widespread adoption across the post production sector. Broadcasters around the world now specify HDCAM SR as a master format for productions where quality cannot be compromised.

• F35 CineAlta Camera Product Information
• SRW-9000PL HDCAM SR Camcorder Product Information

Big budget filming without the big budget
Alongside developments at the top end of our line-up, we are introducing new cameras to ensure we provide the most comprehensive 35mm range for professionals throughout the industry.

Our new PMW-F3 Super 35mm Full HD Compact Camcorder, for example, brings cinematic image quality to DoPs and filmmakers working within tight budgets, fitting seamlessly into industry-standard file-based workflows.

Delivering the powerful creative tools that can capture truly cinematic content, our commitment to the evolution of 35mm enables filmmakers to achieve new levels of artistry and engagement.

• PMW-F3K (with 35mm lenses) XDCAM EX Camcorder Product Information
• PMW-F3L (without lenses) XDCAM EX Camcorder Product Information

＊訊息來源：http://www.sony.co.uk/biz/content/name/ssw-bc-35mm-2010

west

這樣就對了!!
這樣的產品才會令人興奮阿，身邊一堆人已經等很久了。

west

這一堆就可以派上用場了!!
想到就興奮。

alex

PMW-F3K

General

Mass	Approx.2.4kg (Camera only)
Dimension (W x H x D)	Approx.151x189x210mm (PMW-F3L, protrusion not included)
Power requirements	DC 12V
Power consumption	Approx. 24.0 W (Typical) (REC mode, HD-SDI Dual Link On, EVF On, LCD Monitor Off)
Operating temperature	0 to +40°C
Storage temperature	-20 to +60°C
Battery operating time	Approx.130 Min (HD-SDI Dual Link On) (w/BP-U60) Approx.170 Min (HD-SDI Dual Link Off) (w/BP-U60)
Recording format	MPEG-2 Long GOP HD HQ mode: VBR, maximum bit rate: 35 Mb/s, MPEG-2 MP@HL HD SP mode: CBR, 25 Mb/s, MPEG-2 MP@H-14 SD mode: DVCAM Audio: Linear PCM (2ch, 16-bit, 48-kHz)
Recording frame rate	PAL area: HD HQ mode: 1920 x 1080/50i, 25p, 1440 x 1080/50i, 25p, 1280 x 720/50p, 25p HD SP mode: 1440 x 1080/50i SD mode: 720 x 576/50i, 25p NTSC area: HD HQ mode: 1920 x 1080/59.94i, 29.97p, 23.98p, 1440 x 1080/59.94i, 29.97p, 23.98p, 1280 x 720/59.94p, 29.97p, 23.98p HD SP mode: 1440 x 1080/59.94i, 23.98p SD mode: 720 x 480/59.94i, 29.97p
Recording/Playback time	HQ Mode: Approx. 100 min with SBP-32 (32 GB) memory card Approx. 50 min with SBP-16 (16 GB) memory card Approx. 25 min with SBP-8 (8 GB) memory card SP/SD Mode: Approx. 140 min with SBP-32 (32 GB) memory card Approx. 70 min with SBP-16 (16 GB) memory card Approx. 35 min with SBP-8 (8 GB) memory card

Lens

Lens mount	PL mount (w/supplied lens mount adapter)
Focal length	3 lens supplied: 35mm, 50mm, 85mm
Aperture Value	F2.0 to Close
Minimum Shooting Distance	0.35mm (35mm), 0.5m (50mm), 0.85m (85mm)
Focus	Manual Focus
Filter diameter	95mm

Camera Section

Imaging device	Super 35mm Equivalent Single Chip Exmor CMOS Image Sensor
Built-in optical filters	OFF: Clear, 1: 1/8ND, 2: 1/64ND
Sensitivity (2000 lx, 89.9% reflectance)	F11 (Typical)
S/N ratio	63 dB (Typical)
Shutter speed	1/32 - 1/2000 sec
Slow Shutter (SLS)	2, 3, 4, 5, 6, 7, 8 frame accumulation
Slow and Quick Motion function	720P: 1 - 60fps selectable (17-60 fps when HD-SDI Dual Link is active) 1080P: 1 - 30fps selectable(17-30 fps when HD-SDI Dual Link is active)
White balance	Preset, Memory A, Memory B/ATW
Gain	-3, 0, 3, 6, 9, 12, 18dB, AGC

Inputs/Output

Audio input	XLR Type 3pin (female)x2, LINE/MIC/MIC＋48V selectable
Composite output	BNC (x1), NTSC or PAL
S-Video output	n/a
Audio output	RCAx2
Component output	n/a
SDI output	BNC (x1), HD-SDI/SD-SDI selectable
HD-SDI Dual Link Out	BNCx2 4: 2: 2 1080 50/59.94P 10bit output
i.LINK	IEEE1394 S400 4on Connector x1
Timecode input	BNC (x1)
Timecode output	BNC (x1)
Genlock input	BNC (x1)
USB	Mini Type-B connector (x1)
Headphone output	Stereo mini-jack (x1)
Speaker output	Monaural
DC input	XLR type 4pin (male)x1
Remote	8-pin
Lens remote	n/a
MIC	n/a
HDMI output	HDMI connector (Type A)x1

Monitoring

Viewfinder	0.45", Aspect Ratio 16: 9
Built-in LCD monitor	3.5", Aspect ratio 16: 9, Hybrid (semi-transmissive) type

Media

Type	ExpressCard/34 slot (x2)
Interface	ExpressCard compliant

Notes

Supplied Accessories

	PL lens mount adapter
	PL lens kit (35mm, 50mm, 85mm lenses)
	Stereo microphone
	Windscreen
	IR remote
	Shoulder Strap
	CD-ROM (XDCAM Browser, SxS device driver software, PDF Operation Manual)
	Operation Manual
	Warranty Card

alex

Sensitivity ｜ F11
S/N ratio ｜ 63 dB
HD-SDI Dual Link Out ｜ BNCx2 4: 2: 2 1080 50/59.94P 10bit output

嗯！ 好樣的～

getrouble

Shutter speed        1/32 - 1/2000 sec
Slow and Quick Motion function
720P: 1 - 60fps selectable (17-60 fps when HD-SDI Dual Link is active)
1080P: 1 - 30fps selectable (17-30 fps when HD-SDI Dual Link is active)

這個也讓人覺得很好奇可以玩出什麼~~

alex

全新開發的 Exmor Super35 CMOS 感光元件


側邊手握把 Zoom Bar 的設計，似乎暗示未來會推出可電控的 PL 鏡

Shammy42

我還沒見到, 所以也還不會操作..老大歹勢了~
但應該沒F35難吧!

talfy

早前有說資訊流量是 XDCAM SR LITE @ 220Mbps

現在．．．

haoys12

XDCAM 当然是35M了。

希望不要比EX1贵太多

Shammy42

XDCAM 当然是35M了。

希望不要比EX1贵太多
haoys12 發表於 2010-11-8 22:14

XDCAM 真的只有35M的限制嗎?
您是指XDCAM ?
還是XDCAM HD ?
還是XDCAM EX ?

請先查查再留言吧!

國輝

這台神機什麼時候會上市啊?

joewang2003

這台既然稱為 XDCAM, 那 包成 XDCAM MXF 之MPEG-2 Long GOP 50Mbps 422 鐵定會支持
期待站大開箱文, 最重要還是要看到精彩的作品

west

對岸有資訊出來了。
http://dv.it168.com/a2010/1109/1123/000001123700.shtml

画质超单反 索尼发布全新专业机PMW-F3

【IT168 資訊】索尼公司今天在日本發佈了一款超強悍的電影製作級手持DV——PMW-F3，該機採用了一塊名為Exmor Super35 CMOS的高性能感測器（解像度未公開），其尺寸達到了1.7英寸，單位圖元大小是一般35mm全畫幅單反的四倍。得益於這塊超級感測器，索尼PMW-F3擁有極高的感光度和動態範圍，F11（ISO800）和信噪比63dB證明其在低可以保持超高畫質。

發售資訊：2011年2月1日上市，搭載35mm、50mm、85mm三顆T2.0鏡頭（PL卡口）的售價為220萬5000日元（約合人民幣181500元，型號為PMW-F3K），而單機售價為152萬2500日元（約合人民幣125340元，型號為PMW-F3L）。
　　PMW-F3可以拍攝1920×1080解析度的全高清視頻，視頻壓縮採用MPEG-2 Long GOP格式，其存儲格式與之前的XDCAM EX系列通用，並支援DVCAM格式（DV-AVI type2）的標清存儲。另外，該機還支援慢動作、快動作拍攝，當採用720/23.98p格式時可實現1/2.5倍速慢動作（相當於60p）。

　　其他方面，PMW-F3提供一個0.45寸852×480解析度電子取景器以及一塊3.5寸640×480解析度的半投射式液晶屏，其帶有兩個ExpressCard/34插槽，機身介面包括HD-SDI、BNC、HDMI、2個RCA音頻輸出，2個XLR音頻輸入、IEEE 1394、遠端終端以及USB介面等。PMW-F3的機身尺寸為151×210×189mm，重約2.4kg，它所使用的BP-U60型電池最多可連續工作170分鐘。

　　最後不得不說的是，索尼公司同時表示將在2011年推出針對PMW-F3的3D攝像裝置，屆時之要將兩台PMW-F3通過專用電纜連接，然後再通過一台控制終端便可以進行全高清3D攝影。

htjmartin

終於要出來了嗎？？

好像要跟panasonic對打哦

不過標名還是camcorder… 很好奇到底是針對電影還是??..

alex

這台神機什麼時候會上市啊?
國輝 發表於 2010-11-8 23:43

Sony 日本官網公布的上市日期為 2011 年 2 月 1 日

dtses

看這塊頭,應該主要針對電影吧！

kg3173

還不如買RED的機器 至少價錢比SONY一定要便宜很多

alex

還不如買RED的機器 至少價錢比SONY一定要便宜很多
kg3173 發表於 2010-11-10 19:03

請問你是憑感覺，還是真的有查過價錢才發的文？  願聞其詳！

alex

日本廣播電視界的盛會 InterBEE 2010 即將於下禮拜一 (11/15) 開幕，因此 Sony 於日本先行舉辦了 PMW-F3 的媒體見面會，讓大家先賭為快！
（文中照片來源為 PRONEWS 網站）

實機照片中搭配的是 Zeiss 鏡頭，於 LCD 螢幕的外側也看到已打上金色 CINEALTA 的標章


新開發的 Exmor Super35 CMOS 感光元件標誌


後方可看見採用的是 XDCAM EX 家族的 SxS 記憶卡跟 BP-U60 電池


兼容 PL-mount 的鏡頭接環，內置兩組金屬接點


Exmor Super35 CMOS 正面照


PMW-F3K 所搭配的 KIT 鏡頭群組，分別是 35mm, 50mm 跟 85mm，最大光圈皆為 F2.0


未來在開通 Dual Link HD-SDI 輸出 S-Log 的功能後，便可用怪獸的 HDCAM-SR 來做 4:4:4 / 880Mbps 的紀錄


翻拍螢幕畫面，據說因該機種的軔體版本非正式版，故部分功能尚未開通顯示


機身的另一側，很熟悉的 Zoom bar 跟 Audio XLR 輸入介面，但在過去電影機上可是稀有的設計呢！
